Overview: Facilities tab
In location-based routing, facilities control the production of a part on a line. In a facility, the position on the line (station, station index, function number and editing position) is defined with its associated process. To do this, the line reports the processing result of the previous position (e.g. OK or NOK) to the Line Control module and makes a processing request.
Under Line control > Route lists , the positions of the facility (line, station, station index, function number and processing position) with their associated processes are displayed, created and edited in the Facilities tab.
Header
| Element/icon | Description | ||
|---|---|---|---|
<nnn> |
Total number of entries found |
||
|
Search by line, name, version or description. Enter the search term in full or in part.
|
||
Process |
Filter by processes. To do this, select one or more processes from the drop-down list. |
||
|
Export the facilities as a CSV file (e.g. Excel table) or a PDF file. |
||
|
Create facility. |
Facility entry
| Element/icon | Description |
|---|---|
|
Edit facility. |
|
Create and edit facility
Prerequisite
-
LC power userorLC adminrole
Procedure
-
Call up the Line control > Route lists > Facilities tab.
-
In the header, click on
to add a facility.Or:
To edit a facility, use
in the row containing the facility to open the facility for editing.
-
Enter details.
-
Create the new facility with Save.
Or:
Apply the changes with Edit.
The facility appears with the information in the Facilities tab.
Delete Equipment
Prerequisite
-
LC adminrole
Procedure
-
Call up the Line control > Route lists > Facilities tab.
-
In the row of the entry that is to be deleted, remove the facility with
. -
To delete the facility permanently, click on Delete in the dialog window.
The facility is removed form the Line Control module and no longer appears in the Facilities tab.
